What is the transmission rate of these 1.27mm pitch connectors?
Both the plug and socket series support high-speed data transmission rates up to 11 Gbps, making them ideal for high-speed signal integrity applications.
What are the available pin configurations for these series?
These connectors support a wide range of pin counts, ranging from 20 PIN up to 200 PIN configurations, providing flexible options for different circuit board designs.
What materials are used for terminal and insulation housing?
The insulation material is a high-temperature resistant black Liquid Crystal Polymer (LCP), and the terminal material is durable Phosphor Bronze with up to 30u" gold plating over nickel.
Can these connectors operate in extreme temperature conditions?
Yes, both the plug and socket are designed to operate reliably across a wide temperature range of -55℃ to +125℃.
Are these electrical connectors Lead-Free and environmentally compliant?
Yes, both the plug and socket models are manufactured under lead-free standards to ensure environmental compliance.
What is the coplanarity specification for SMT soldering?
The coplanarity of these four-row surface mount connectors is specified at 0.15mm, ensuring high reliability during the reflow soldering process.
