Material Number
81A08-XXXVOX. XH10T-XX
Insulation Material
Black LCP
Terminal Material
Phosphor Bronze
Plating Options
Max 50u" Gold Plated on Nickel
Rated Current
1.8A per pin @ 95℃ (2 pins powered)
Rated Voltage
175 VAC
Matching Height
6.00 mm - 12.00 mm
Pin Size
10 Pin to 100 Pin
Operating Temperature
-55℃ to +125℃
Transmission Rate
14 Gbps
Mating Times
100 Cycles
Coplanarity
0.15 mm
Environmental
Lead-Free
What is the transmission speed of this plug and socket connector?
This connector supports high-speed transmission rates up to 14 Gbps.
What materials are used for the insulation and terminal?
The insulation material is high-performance black LCP, and the terminal material is Phosphor Bronze with plating options of up to 50u" Gold Plated on Nickel.
What is the operating temperature range for this connector?
It is designed to operate in extreme environments with a temperature range of -55℃ to +125℃.
How many mating cycles can this connector withstand?
This 0.80mm pitch plug and socket same-body connector is rated for up to 100 mating cycles.
What pin sizes and matching heights are available?
The connector is available in pin sizes ranging from 10 pin to 100 pin, with matching heights between 6.00 mm and 12.00 mm.
Is this connector product Lead-Free compliant?
Yes, this connector series is completely Lead-Free compliant.
