Three-Groove Locking Mechanism: Enables quick mating and unmating operations
Automatic Sealing: Prevents leakage by maintaining automatic sealing upon disconnection
Leak-Free Operation: Ensures no internal fluid leakage during normal plugging/unplugging
Optimized Valve Design: Maximizes flow rate through precision-engineered internal valves
Durable Construction: Shell and plating offer high resistance to wear and corrosion
Customizable Tail Interface: Contact the company for tailored configurations

Send Inquiry

Product Description

Applications & Operational Environment

The YTN series fluid connectors are widely used in various liquid cooling systems, mainly for connecting large-flow liquid cooling equipment.

Technical Performance

Operating Temperature -55 °C to +95 °C

Operating Pressure 0~2MPa

Working Medium Coolant, Deionized Water, etc.

Seal Ring High-strength fluorosilicone rubber, EPDM rubber

Mechanical Life 1000 mating cycles

Housing Material Surface-treated Aluminum Alloy, Stainless Steel

Vibration and Shock Meet the requirements of vehicular, marine, and other applications

Salt Spray Test 96h

Frequently Asked Questions (FAQ)

Q What are the typical applications for YTN series fluid connectors?

They are widely utilized in various liquid cooling systems, primarily for connecting large-flow liquid cooling equipment.

Q What is the operating temperature range for these connectors?

The connectors can reliably operate in temperatures ranging from -55 °C to +95 °C.

Q What working media are compatible with the YTN series?

They are designed to work with coolants, deionized water, and other compatible cooling fluids.

Q What housing materials are available?

The connectors feature housings made of surface-treated Aluminum Alloy or Stainless Steel to ensure durability.

Q How many mating cycles can the YTN series connectors withstand?

The connectors offer a mechanical life of up to 1000 mating cycles.

Q Do these connectors meet vibration and shock resistance standards?

Yes, they meet the rigorous vibration and shock requirements for vehicular, marine, and other demanding applications.
