The 800X Series connectors support a high-speed transmission rate of up to 21Gbps, making them ideal for high-performance transmission networks.
The insulation is made of robust black LCP (Liquid Crystal Polymer) and the terminal material consists of high-durability beryllium copper.
These connectors are designed to operate reliably in extreme environments, supporting temperatures ranging from -55℃ up to +125℃.
The connectors are tested for high durability and are rated to endure up to 100 mating cycles without performance degradation.
Yes, both the M05 and F05 models of the 800X Series 0.50mm Pitch Connectors are certified as Lead-Free.
The series offers a wide layout configuration ranging from 10 PIN to 150 PIN, with matching heights varying from 7.00mm to 12.00mm.
